FP ENERGY

Description

This model is available in sealing only and/or MAP.

The ENERGY is capable of sealing a Family Style Tray one per cycle, and one to two #3 (Industry Standard) size trays per cycle. With the proper components, this model can achieve up to 200 cycles per hour with  MAP and 300-400 without MAP (operator dependent). With up to 4 impressions per cycle (depending on tray size) this little machine can push out big production.

The ENERGY Tray Sealer is composed by utilizing a simple, easy-clean design and change-overs are inexpensive and performed within 2-5 minutes!

Sealing force has been increased to 800lbs.

Tested and approved for HPP (High Pressure Processing) quality seals.  NOT capable of Skin packaging, running flat boards, or utilization of 10K film.

Perfect solution for University Food Science programs. Ask a sales representative about of discount opportunities for this model today for any collegiate program.

***ASK US ABOUT OUR EQUIPMENT FINANCING SOLUTIONS, INCLUDING 0% FOR QUALIFIED CUSTOMERS***

*All the companies of the ILPRA Group operate according to ISO 9001:2008 compliance and their organization of production is fully internal. Before delivering, each machine undergoes the scrutiny of strict internal test procedures, carried out with the packaging materials received from customer. This procedure verifies that the product is in compliance with both the customer and the regulations in force with Ilpra.

Request for Quote: FP ENERGY

Request a Quote

  • Hidden

Specifications

ENERGY VG LAYOUT

Electrical – 220V-230V 1 Phase – 60 Hz

Recommended Breaker size w/ Standard Busch 21 (1.2 HP) – 20 AMP Breaker

Max film OD – 200mm

Compressed Air required – Yes

Compressor included – No (Please speak to your dealer to assure proper pump)

Compressed Air requirements – 6 bar (90 psi) Constant Pressure *Dryer Mandatory*

Compressed Air consumption – 2-3 CFM per machine (@ 6 bar – 90 psi)

Machine weight – 150lbs (base excluded)

Gas Connection / Hose – 1/4″ NPT / ¾” ID Hose

Gas Pressure to machine – 1 bar (15 ps)

Pneumatic Connection / Hose – 1/4” NPT / 3/8” ID Hose (or larger)

Protection class – IP 65

Certification – CE
